Camera
Image Sensor: | 1/2.8″ Progressive Scan CMOS
Min. Illumination: | 0.01Lux @ (F1.2, AGC ON) ,0 Lux with IR
Shutter time: | 1/3 s to 1/100,000 s
Lens: | 2.8mm, 4mm, 6mm @ F2.0 angle of view: 109.4°(2.8mm), 90°(4mm), 53.9°(6mm)
Lens Mount: | M12
Adjustment Range: | Pan: -90° ~ 90°, Tilt: 0° ~ 75°
Day& Night: | IR cut filter with auto switch
Wide Dynamic Range: | 120 dB
Digital noise reduction: | 3D DNR
Compression Standard
Video Compression: | H.264/MJPEG/H.264+
H.264 code profile: | Main Profile
Video bit rate: | 32Kbps~16Mbps
Max. Image Resolution: | 1920 x 1080
Frame Rate: | 50Hz: 25fps (1920 × 1080), 25fps (1280 × 960), 25fps (1280 × 720)
60Hz: 30fps (1920 × 1080), 30fps (1280 × 960), 30fps (1280 × 720)
Image Settings: | Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser
BLC: | Yes, zone configurable
ROI: | Support
